The image may differ from the original
M12 flange connector with 4 poles for SMT mounting, IP67 protection rating. Unshielded version with M12x1.0 screw-lock mechanism for front mounting on printed circuit boards.
€ 6,80
| Series | Series 713/763, Series 763 |
|---|---|
| Numberpole | 3–12, 4 |
| Connection type | SMT |
| Lock | Screw M12, screws |
| IP rating | IP40/IP67/IP68/IP69K |
| Rated voltage | 30–250 V |
| Rated current | 1.5–8 A |
| Temperature range | -40°C / +85°C |
The Binder M12 flange connector 99 3431 351 04 from the 763 series is a 4-pin connector in an SMT (Surface Mount Technology) design for modern automated manufacturing processes. Surface-mount technology enables efficient and cost-effective assembly using pick-and-place machines.
With an IP67 protection rating, the connector is protected against dust and temporary submersion, making it suitable for demanding industrial environments. The M12x1.0 thread with screw lock ensures a mechanically robust and vibration-resistant connection. Front mounting allows for space-saving integration.
The unshielded 4-pin version is ideal for standard applications in automation technology where there are no heightened EMC requirements. SMT technology reduces assembly costs and enhances process reliability in series production.
Main applications: Industrial sensor technology, control engineering, mechanical engineering, testing and measurement technology. Particularly suitable for high-volume production and automated manufacturing. Manufacturer: Binder (binder-connector.com).
