The image may differ from the original
M8 4-pole flange connector from Binder’s 718 series for rear-panel mounting. Shieldable, THT connection, screw-lock M8x1.0, IP67 protection rating. UL 2238 certified for industrial sensor and actuator applications.
11 in stock
€ 7,56
| Series | Series 718, Series 768/718 |
|---|---|
| Numberpole | 3–12, 4 |
| Connection type | THT |
| Lock | screw/snap-in, M8 screw |
| IP rating | IP65/IP67/IP69K |
| Rated voltage | 30–60 V |
| Rated current | 1.5–4 A |
| Temperature range | -40°C / +85°C |
The M8 flange connector with part number 86 6319 1120 00004 from Binder is a 4-pole sensor/actuator connector from the 718 series, designed for rear-panel mounting in control cabinets and automation systems. The shieldable version ensures reliable signal transmission even in EMC-critical environments.
The connector features a THT (Through-Hole Technology) connection for PCB mounting and a robust screw-lock mechanism with an M8x1.0 thread. The IP67 protection rating provides protection against dust and temporary submersion, making it ideal for industrial environments. UL 2238 certification confirms its suitability for North American markets.
Typical areas of application include sensor networks in factory automation, the interconnection of actuators in material handling systems, and fieldbus installations. The M8 design has established itself as the industry standard for compact sensor/actuator cabling.
Rear-panel mounting allows for space-saving installation directly onto the printed circuit board. Thanks to its shieldable design, the connector is particularly suitable for applications with stringent EMC requirements in process automation and machine control.
